Mixed antenna Omnidirectional TV 12/24V + Digital TV Receiver fo
[61479400]

Mixed antenna Omnidirectional TV 12/24 V DC

Built-in advanced RF technology amplifier, perfect signal reception (360°)
Also suitable for radio station reception FM.
Designed for indoor and outdoor uses
Water proof & UV-rays resistant.
Easy to installing, including mounting accessories
UHF full TV signals reception.
Can be connected to an external antenna
Built-in high gain and low noise head amplifier
12/24 Volt DC Operation with a power supply adaptor.

Charactéristics :

• Receiving range : UHF/FM
• Frequency : 470-860 Mhz
• Gain : 30 dB
• Impedance : 75 ohms
• Power supply : 12/24V
• Indoor & outdoor

• Rotative 360°


Provided elements :

• Antenna
• Base
• Adapter 12/24 Volt CC
• Metal fixer & screws

• 12/24 Volts DC adaptor

• Coaxial cable

Digital TV Receiver for laptop

The TV TNT it is possible with your portable PC !

Specificities :

• Ultra-compact USB digital TV receive and recorder

•  DVB-T protocol (ETS 300 744) compliant

• Plug & Play, powered by USB port

• Full channel and territory auto scan

• Real-time digital video recording and saving into the MPEG2 format

• Infrared remote control

Charactéristics :

• Fréquences de réception: 48.25-855.25MHz
• Receiving Frequency: 48.25-855.25MHz

• Demodulator and FEC: Channel Bandwidth: 6, 7, 8MHz

• Constellation: QPS, 16QMA, 64QAM

• OFDE MODE: 2K or 8K

• Code Rate: 1/2, 2/3, 3/4, 5/6 or 7/8; Guard Interval-1/4,1/8,1/16 or 1/32

• Support MPEG-2、MPEG-4、H.264 Format Video Receiving

• USB SPAC1.1/2.0 Compliant


SYSTEM REQUIREMENTS :

• Processeur: Pentium E 2.0G, Intel Core or AMD Athlon X2 2.0G
•  CPU: Pentium E 2.0G, Intel Core or AMD Athlon X2 2.0G

• OS: Microsoft(R) Windows Media Center Edition 2005, Windows(R) XP with Service Pack 1/2, Vista, not compatible with Mac OS.

• System Memory: 1G.

• Video Memory: 512M

• Disk Space: 600MB for DVB-T Mini Driver and Application Plus 25-30MB per Minute to Record Video.

• Graphic Card: 1024*768, Director X 10 Compatible.

• Sound Card: AC 97 Compatible PCI Sound Card.

• CD or DVD-ROM Drive: To Install The Drivers and Application.

• Interface: One Available USB Port.


PACKAGE CONTENTS :

•  USB DTV-T Receiver 2.0 Hi-Speed

• Portable Antenna for home use only

• Infra-Red Remote Controller

• Adapter for external TV antenna (Indoor / Outdoor uses)

• Driver and Application CD-ROM operating in 12 languages

• Laptop non included
